FoxAlien Reizer 20W Laser Engraver
SKU: CNC-LE-Reizer |
$329.99
$499.99
Save $-170.00
Free Shipping in U.S.
Fast Delivery
International Shipping Available
Lifetime Customer Support
- 【Upgrade 32-bit control board】The Reizer laser engraver equips with a 32-bit control board and an adjustable Z-axis for easy focusing. The 32-bit control board enables the machine to work more stably and smoothly.
- 【Compressed laser beam technology】It has a 20W fixed-lens laser module with laser beam compression technology. The laser dot is only 0.12*0.08mm. This laser module has great performance in cutting and engraving, especially engraving delicate projects and details.
- 【One-click to HOME & Test fire button】HOME and test fire function are integrated to the control board. Long press to HOME; short press to turn on the laser in weak light.
- 【Easy assembly】Main parts are pre-assembled. It takes about 15-20 mins to fully assembly. Belt-driven design reduces the working noise to low level. The machine is compatible with Grbl software. It supports Windows, Linux and Mac OS.
- 【Applicable to a variety of material】Reizer laser engraving machine is capable to handle different kinds of material such as wood, leather, acrylic, EVA foam, cardboard, vinyl, and coated metal surface etc. It is widely used in many fields.
Reizer is designed with fast assembly and simple using. It enables hobbyists, amateurs and even beginners to explore the engraving world, to create their own works and have fun!
Features:
- Fine workmanship: aluminum body frame, metal parts for stable performance.
- Dual Y-axis motors: machine moves more stably and smoothly with 2 Y-axis step motors.
- Easy Wiring: all wires are labeled clearly and bundled into the drag chain neatly.
- Newly designed control board with reserved ports for DIY upgrade.
- Laser module position is adjustable by the knobs.
- Low noise: working noise is about 60dB.
!!! Notice:
Each machine has been set up for aging testing in the factory and then disassembled for packing. We guarantee each machine is brand new.
Specifications:
- Engraving Area: 40 x 40cm/ 15.75 x 15.75 inches
- Step Motor: 42 step motor
- Accuracy: 0.1mm
- Laser Module Power: 20W (Fixed Focus)
- Recommend Focus Distance for Cutting: 30mm
- Electric Output power: 20W
- Laser Output power: 5W-5.5W
- Power Supply: 12V/5A
- Support Software: Lasergrbl, Candle, Lightburn, Compatible with all GRBL software
- Support OS: Windows XP, Windows 7, Windows 8, Windows 10
- Laergrbl only can be used in Windows, Lightburn can be used in Windows and MacOS
Package List:
- 1x Reizer Engraving Machine (Main Parts Pre-installed)
- 1x 20W Laser Head
- 1x Power Supply
- 1x USB Cable
- 1x U Disk
- 1x Goggle
- 1x User Manual
- Packs x Screws
