FoxAlien
CNC Router Masuter Pro
SKU: CNC-Masuter-Pro |
Structure Upgrade: Masuter Pro is an All-Aluminum CNC router, which makes the machine sturdier than the last version. The Z-axis uses linear rails instead of the optical axis, this greatly improves the stability and accuracy.
Upgraded Controller Box: The control board is upgraded to a compact controller box. The emergency stop button and home button are more easily and more convenient to access. The control box is also dust-proof for easy maintenance.
Compatibility Upgrade: Masuter Pro includes 2 spindle clamps: 52mm & 65mm. The 52mm clamp can accommodate the 60W spindle, 300W spindle and the FoxAlien laser modules. The 65mm clamp is for customized upgrade, such as 65mm Makita router, 1.5KW spindle, etc. Masuter Pro also supports the 69mm spindle clamp, please buy separately.
Assembly Upgrade: Main parts are pre-assembled, and the part of the wires are pre-installed to the controller box. It takes only 10-15 minutes to fully assemble.
Additional Working Light: A small working light is added to the Z-axis. It helps you to monitor the carving details and process more clearly. Each stepper motor has a knob for easy adjusting by hand.
Specifications:
- Active Working Area: 15.75” x 15.75” x 2.36” (400 x 400 x 60mm)
- Spindle: 775; 10000RPM
- Input Supply: 12V/5A
- Stepper Motor: 1.3 A, 12V, 0.25 Nm torque (2.2 in lb)
- Supported OS: Windows XP/7/8/10/11, MAC OS, Linux
Package List
- 1x Masuter Pro CNC Router Machine (Main part pre-installed)
- 1x Z Probe
- 1x Controller Box
- 4x Hold-down Clamp
- 1x 52mm Spindle Clamp
- 1x 65mm Spindle Clamp
- 1x Power Supply
- 1x USB Cable
- 1x U Disk
- 1x User Manual
- 10 x Router Bits
- Packs of screws
Customer Reviews
The machine was easy to assemble but I am having trouble getting the programming. I have downloaded online software just not getting it to the Cnc.
Ive been using the MP with extention kit for about 7 months now. There are definitely some limitations with the Z-Axis heights, but you can overcome them with some simple engineering. I do wish the stepper motors had a little more power and may look into upgrading them at some point. Would definitely purchase it again. They've been phenomenal to work with as well.
So far it works great, but have not really had time to work with it. Also, it is not mine purchased for son and this is his response.
it is a kit for good money. I've only had it for a month. I made an extension of the surface, put stronger motors and bearings for tensioning the belt. Now it works like a charm😁 most often I machine wood with a 6mm router and at a speed of 1600 to 2000mm per minute.
This Machine is a rockstars
I have had a great experience from the ordering to the delivery. The machine was easy to assemble and fun to learn. I was looking for an upgrade to my woodworking hobby and this machine foots the bill. Both the price and the quality were what I needed. I am happy with my purchase so far.
FoxAlien got 100% from me on this CNC router. The package was neatly packed, promptly shipped with excellent colorful instructions. CNC machine itself was well produced and function really good and I am looking forward to productive projects.
I will like to suggest that the controller should be made to allow for GRBL updates via SD card interface.
Setup went well for me, spoilboard created thanks to James Dean Designs. First project went off without a hitch. Still experimenting and looking forward to it!
I purchased the Masuter Pro and received it about 2 weeks ago. I am truly impressed with this machine and I haven't even upgraded anything yet. I plan on getting the router set up within the next month. But, with the 60 watt spindle I have been able to carve several projects without any issue. A great buy, I am VERy happy with this purchase.
I have a lot of experience with laser CNCs and 3D printers. Never a CNC routers. I bought the Masuter Pro with the 60w spindle because the low entry price and ability to upgrade it. Overall experience has been positive. Communication with FA has been great even with the time difference from the states to their HQ. The build was a very simple process. Directions were easy to follow, plus there are some great videos on YouTube. Out of the box, everything is square enough to make some test cuts. I would still recommend fine tuning the machine to guarantee accurate cuts. Again, there are great YouTube videos out there. I have only made a few cuts but they all seem to get better than the last one. Expect a learning curve with the CAM side of things! There is also some great resources on Facebook.
